Performance
use:This machine melts
the international advanced technology
and a Chinese national condition body.
It through the specialpulp, the dye
printing craft, anchors the gold shifts
to the fabric surface, also can cause
the fabric corrugation.
It puts the material intaglio dye
printing unit by a group, the air
operated thermo-compression unit,
the dry drying oven and receives the
material unit, the electrical machinery
uses the frequency conversion control,
the control balance, saves the energy.
Technical
parameter: Gate: 1600-1800m/m
vehicle speed: 5-40m/min may move
Hot roller power: 9¡Á2kw=18kw temperature:
50-250 ¡æ
Hot roller diameter: ¡õ350m/m silica
gel roller diameter: ¡õ390m/m
Drying oven power: 18¡Á2kw=36kw temperature:
50-150 ¡æ
Transmission power: 6.75kw installing
equipment total output: 60.75kw
Contour heart inch 10620m¡Á2600m¡Á2700m
|
